Technical Specification
CUTTER SIZE RANGE | 12 – 125mm TCT |
MAX CUTTER CAPACITY | 125mm TCT |
TWIST DRILL CAPACITY | 32mm |
MAX TAP CAPACITY | M32 |
MAX COUNTERSINKING | 65mm |
LENGTH | 345mm |
WIDTH (Inc Handles) | 240mm |
HEIGHT (Min-Max) | 470 – 750mm |
STROKE | 280mm |
WEIGHT | 25 kg |
MAGNET (L X W) | 220 x 115mm |
MAGNETIC ADHESION | 2200 kgs |
MOTOR POWER | 1800w |
TOTAL POWER | 1900w |
SPEED RPM (No Load) | 60-140 / 100-220 / |
140-310 / 210-490 | |
SPINDLE | MT3 |
ARBOR | 19,05 mm (¾”) Weldon |
TAKES CHUCK | Yes |
COOLANT SYSTEM | Gravity Oil Fed |
WARRANTY | 2 Year |
Standard Kit: supplied with handles, heavy duty metal sliding guard system, MT3 broaching arbor, VersaDrive arbor. Supplied in transport packaging WITHOUT Case to reduce cost for users who do not need or wish to store it inside a case.
Pro Kit: As above plus heavy duty, waterproof, shock-resistant site case, gravity fed coolant system and VersaDrive Quick Change Arbor in place of the standard VersaDrive Arbor
